BFT GIOTTO BT A 60S 24V Barrier Gate Opener

24V barriers for intensive and very intensive use, able to manage useful passages up to 6 m. Integrated control unit with U-Link connectivity.

Equipped with 24Vdc motors, they have a range of accessories making them ideal in any context.

Scenario programming: the MERAK BG control units enable extremely rapid and precise installations thanks to the scenario programming of the installation. In fact, with just a few choices made on the display it is possible to program the control unit completely, saving time and ensuring the best results.

Control unit in upper position: the control unit located at the top of the barrier and protected by a solid aluminium housing enables connection, programming and maintenance operations to be performed with maximum ease and convenience.

Key features

  • Encoder technology
  • Electronic limit switches
  • Control with U-Link and programming display

Technical Specifications

Power supply 230V±10% 50Hz
Motor Input Power 300W
Internal lubrication permanent grease
Max torque 380 Nm
Opening time 4s
Boom length 6 m
Manual mechanical release customised key
Type of boom rectangular
Limit devices electrical incorporated and electronically adjustable
Type of use intensive
Working temperature from -20°C to +55°C
Protection rating IP 54
Operator weight 42 kg
