Centsys I5 Wired Safety Beam Photocell Sensors
* Roll over the image to zoom in
Centsys I5 Wired Safety Beam Photocell Sensors System Garage Gate
Centsys I5 Wired Safety Beam Photocell Sensors:
i5 infrared beams from are simple to align, extremely reliable and boasts an operating range of up to 40m. It can be used on gates, garage doors, and even for simple perimeter protection.
Features:
- Wide infrared beam makes for supremely easy beam alignment – no more battling onsite.
- Highly cost-effective detection solution.
- Easy commissioning thanks to LED indicators.
- 40 metre range – suitable for even the widest of entrances.
- Compatible with Intruder-detection Alarm functionality (a world first) – greatly improves security.
- Wide input voltage range.
Specifications:
- Power Supply: 12 - 24V DC/AC
- Power Consumption Transmitter: 21mA
- Receiver: 43mA @ 12V
- Max DistanceL 40m
- Alignment: Automatic - 9m2 @ 10m (Parallel - Circular Area)
- Output Contact Rating: 5A @ 220V AC (non-inductive)
- Operating Temperature: -15°C to +55°C
- Operating Humidity: 0% - 90% (non-condensing)
- Degree of Protection: IP54
Includes:
- 1 x Genuine Centsys i5 Wired Safety Sensor Photocells (Pair)
